BSDII blind spot detection system with Nonam mirrors compatible with Harley Davidson Street 500/750
$612.00
$510.00
You save:
$102.00
In Stock
SKU: 100162319188603
BSDII blind spot detection system with Nonam mirrors fit for Harley-Davidson Street 500/750, sold as a pair.
Description
Blind spot detection has been available on cars for a number of years. Now KiWAV presents the future of motorcycle safety product -- BSD system for motorcycle. Compatible with Harley Davidson Street series.
Compatible Motorcycle Models
(Compatibility doesn't ensure suitability. Please verify the mirror measurements.) (Contact us with newest models not listed.)Harley-Davidson
- Street 500 XG500 (2014-2020)
- Street 750 XG750 (2014-2020)
Measurement
*Please allow ±3% measuring deviation due to manual measurement.
Instruction
How to install grips on your bike handlebar?
Installation guide
SPEC
- Features
- A revolutionary safety product to monitor the blind spots with an advanced radar sensor while riding your motorcycle. Modern cars now have this technology and it only makes sense that your motorcycle does too.
- A built-in LED indicator on both sides of rear-view mirrors. It signals you when there is traffic coming into your blind spots. This will increase rider awareness of surrounding traffic conditions.
- With the Magazi BSD system 79 GHz short-range radar, you can ride with more confidence and safety. The warning zone of the system covers left and right adjacent lanes with up to 25m(82ft) range.
- The BSD system is automatically activated when the motorcycle is started, low power consumption and high reliability.
- Easy installation - most motorcycles can be equipped in under an hour, with one radar sensor mounted to the license plate frame. Power for the system is from the bike's 12V acc power source. Then, indicators that light up are built-in in the mirror.
- Swivel adjustable ball joint, find the best rear view angle and ready to go.
- Wider vision with convex lens and E-mark approved.
- Material
Mirror Housing: reinforced ABS
Mirror Stem: Aluminum
BSD radar body: Hi-impact plastic housing
BSD radar bracket: Aluminum - Color
Black - BSD SPEC
Operating frequency: 79 GHz
Multifunctional: BSD and LCA
Storage temperature: -40°C ~ +90°C
Operating temperature: -40°C ~ +85°C
Input voltage: 12V
Distance measurement: RCW 25m
Speed measurement: 5~+70 kph
Current consumption: 126mA @12V
Dust & waterproof compliant: IP67
Specifications: ISO 16750
Radiation regulations: FCC/NCC
- Glass
Chrome convex lens - Weight
n.w.: 1373 g./ 3.02 lbs. (pair),
g.w.: 1721 g./ 3.79 lbs. (total package, packing inclusive) - Package
A pair of mirrors (left hand / right hand),
10mm standard thread bolt x2, 10mm reverse thread bolt x1,
8mm standard thread bolt x2, 8mm reverse thread bolt x1, bolt cap x2,
5/16" bolt x2, wire harness set x 1,
BSD radar x 1, bracket for radar (L type) x 1, bracket for license plate x 1
- Compatibility
Harley Davidson XG Street 500 2015-
Harley Davidson XG Street 750 2015-
*These mirrors do not fit a Street Rod 750 (XG750A).
For Street Rod 750 (XG750A), please check our bar end mirror selections.
If you wish for a perch mount style mirror for Street Rod 750 (XG750A), you would need to customize the mount.
*Please must check the NOTES below.
Our BSD system is NOT RECOMMENDED if your motorcycle has:
1. The exhaust placed too close to the license plate, the heat from exhaust gases will damage the radar sensor.
2. The license plate is not located directly behind the motorcycle.
3. The distance from the ground to the license plate is lower than 60 cm (23.62 inch) or higher than 80 cm (31.5 inch).
4. There is no space for the radar sensor on the both sides of the license plate. (you can download the template to measure and find out.)
1. The exhaust placed too close to the license plate, the heat from exhaust gases will damage the radar sensor.
2. The license plate is not located directly behind the motorcycle.
3. The distance from the ground to the license plate is lower than 60 cm (23.62 inch) or higher than 80 cm (31.5 inch).
4. There is no space for the radar sensor on the both sides of the license plate. (you can download the template to measure and find out.)
Footage
The on road recording
Video
